PufferTouch
PufferTouch
Made to touch.
The world’s leading touch-enabled spherical display.
Irresistible interactivity.
Captivate your audience with multi-touch storytelling. Our gesture recognition capabilities take user interaction to a whole new level. Whether you’re spinning the globe, pinching to zoom, or swiping through images, the system effortlessly recognises your gestures and translates them into actions.
Our touch system allows up to 64 fingers to interact simultaneously with the display surface, enabling a truly immersive and collaborative experience.
Create wonder in any space.
The touch system supports multiple users simultaneously, making it perfect for collaborative environments such as classrooms, conference rooms, and interactive exhibitions.
Our 1.5 megapixel optical touch system has a refresh rate of 60 Hz giving rapid, fluid response to user interaction.
Brilliant. From every angle.
Built to withstand the demands of continuous use, our touch system combines robust hardware and cutting-edge touch technology to deliver long-lasting performance. From temporary to permanent installations, the PufferTouch delivers every time. Using our market-leading proprietary solutions, you can be sure that your message will be delivered with precision and clarity. Trust us to tell your story in the way that only a PufferTouch can.
Three sizes. One way to wow.
The PufferTouch is available in three standard sizes.
600mm in diameter
760mm in diameter
900mm in diameter
The all important details.
PT 600
Screen Size
600(2’)
Resolution
4K
Pixel Density
51.55
Average Pixels Size
0.24
Dimensions
H1424mm, diameter 1000mm (base)
Housing (Other housings available)
Powder coated aluminium (black or white)
Optimum ambient light
7,000
100 lux – Internal lobbies/hallways
9,000
300 lux – Conference venue/experience centre
12,000
100 lux – Internal lobbies/hallways
PT 760
Screen Size
760 (2½’)
Resolution
4K
Pixel Density
40.52
Average Pixels Size
0.39
Dimensions
H1582mm, diameter 1000mm (base)
Housing (Other housings available)
Powder coated aluminium (black or white)
Optimum ambient light
7,000
–
9,000
100 lux – Internal lobbies/hallways
12,000
300 lux – Conference venue/experience centre
PT 900
Screen Size
900 (3’)
Resolution
4K
Pixel Density
33.75
Average Pixels Size
0.57
Dimensions
H1722mm, diameter 1000mm (base)
Housing (Other housings available)
Powder coated aluminium (black or white)
Optimum ambient light
7,000
–
9,000
–
12,000
100 lux – Internal lobbies/hallways
The finer points.
Light
Light Source
Laser diode laser class 1
Projection
Single chip DLP
Light Source Life
Up to 40,000 hours
Software
OS
PufferOS
Software
PufferCore
HD and connections
Storage
1TB SSD
Audio Output
Line out 3.5mm jack connector
VIDEO Output
DisplayPort
Network
IEEE802.3 and IETF standards: 10/100 Base-T Ethernet, IPv4/IPv6, TCP, UDP, RTP, RTSP, ICMP, IGMP, SNMP, HTTP, HTTPS, PPPoE, uPnP, QoS, DHCP
Operation
Electrical
110 – 240V 1440W Max
Operating Humidity
20-80% RH
(non-condensed)
Operating Temperature
10° – 35°C
Operating Standards
EN55035:2017, EN55032:2015, FCC18
